Tank Systems

Stenner Tank Systems

Tank Systems consist of Stenner's tank and peristaltic pump and is built with any of the following pumps Classic Single Head Adjustable, Classic Single Head Fixed, M128, and the Econ Pump Line.

Need Answers?

Item Number
Inquiry
Downloads

Shipping Weight and Dimensions

Tank SizeShipping WeightProduct DimensionsBox Dimension
Classic Adjustable
or M128
Classic
Fixed
Econ
7.5-Gallon24 lbs (10.9 kg)23 lbs (10.4 kg)19 lbs (8.6 kg)20.5 OD x 19.6 in.
(52.1 OD x 49.8 cm)
23 x 23 x 21 in.
(58 x 58 x 54 cm)
15-Gallon27 lbs (12.2 kg)26 lbs (11.8 kg)22 lbs (10. kg)20.5 OD x 25.3 in.
(52.1 OD x 64.1 cm)
23 x 23 x 27 in.
(58 x 58 x 66 cm)
30-Gallon34 lbs (15.4 kg)32 lbs (14.5 kg)28 lbs (12.2 kg)20.5 OD x 37.5 in.
(52.1 OD x 95.3 cm)
23 x 23 x 39 in.
(58 x 58 x 97 cm)
Materials of Construction
TankPolyethylene
Lid with child resistant lockPolypropylene
GrommetsViton
ScrewsStainless steel

Agency Listings

Agency Listings

Guardar

Stenner Tank Systems are shipped pre-assembled to save time and money on installations.

The Tank Systems consist of the tank and pump and is built with any of the following pumps Classic Single Head Adjustable, Classic Single Head Fixed, M128, Econ FP, Econ T, Econ Stennicator, Econ Integrator™, Econ VX and FX. To build a part number, click here.

Select from three sizes and two colors.

7.5-gallon (28.4 liters)
15-gallon (56.8 liters)
30-gallon (113.6 liters)
UV resistant gray
Translucent white

The polyethylene construction is both lightweight and rugged. The tank has incremental solution level indicators and is equipped with a child resistant lid. The pumps are vertically mounted over the tank's containment basin. A rain roof is included with Classic series models to help protect the motor in outdoor installations.Tanks are also sold separately.

Stenner's Tank System Overview
Tank system with Classic Series
single head adjustable pump

The Stenner Mixer is designed to fit the tank system or tanks and is typically utilized when injecting solutions that are difficult to keep in suspension.

Installation Instructions
Spec Sheet
